Retaining Wall Instructions
This file is a simple informational page on how to build a Retaining Wall.
Retaining Wall Instructions.pdf
Adobe Acrobat document [380.5 KB]

WedgeRock®

The WedgeRock® Terrace Block retaining wall system was designed and developed to meet the needs of local designers, landscapers, and homeowners. Since then, WedgeRock® blocks have been installed on commercial, residential, city and state projects throughout the Midwest and have become a proven and durable system.

WedgeRock® Terrace Blocks are beautiful and permanent. They are made of concrete with a rock face finish and a deep V at each end to give a shadow effect. When these blocks are laid up, they cast a shadow that enhances the natural beauty of the rock face. Installation is so simple. Stack WedgeRock® one row at a time and fill the cores as you go. The patented polyethylene pin provided automatically establishes the 1/2" setback per course for the wall and locks the blocks together from one course to the next. It is the simplest retaining wall system you can install. No mortar is required.

The unique shape of WedgeRock® blocks were so designed to promote the easy construction of serpentine curves (combining inside and outside curves in one segment) or just curved walls.

WedgeRock®

Colors: Gray, Tan, Brown, or Charcoal

Size: 16" Wide x 8" High x 12" Deep

Face: .85 Square Feet

Weight: 64 lbs.

48 per Cube plus Wood Pallet

WedgeRock® Cap

Colors: Gray, Tan, Brown, or Charcoal

Size: 16" Wide x 4" High x 12" Deep

Weight: 54 lbs.

48 per Cube plus Wood Pallet

WedgeRock® Corner

Colors: Gray, Tan, Brown, or Charcoal

Size: 16" Wide x 8" High x 8" Deep

Weight: 42 lbs.

72 per Cube plus Wood Pallet

WedgeStone™

WedgeStone™ gives a natural stone-like look in a variety of colors. It’s easy to install with a minimum amount of time. The built-in lip automatically sets each row back 3/4". Suggested wall height is 2 1/2 feet but can be laid up to 3 feet if the right conditions exist.

The block are rock faced on 3 sides to give it a dimensional look. Bug and rot free to last a lifetime.

WedgeStone™

Colors: Gray, Buff/Tan, Copper/Black, Charcoal/Gray, or Red/Black

Size: 16" Wide x 4" High x 8" Deep

Face: .44 Square Feet

Weight: 33 lbs.

90 per Cube plus Wood Pallet

WedgeStone™ Cap

Colors: Gray, Buff/Tan, Copper/Black, Charcoal/Gray, or Red/Black

Size: 16" Wide x 4" High x 9" Deep

Weight: 33 lbs.

90 per Cube plus Wood Pallet

Wedgies™

Wedgies™ are designed for small retaining wall jobs. There's no end to the places they may be used: around flower beds, trees, lamp posts, patios, driveways, and others limited only to your own imagination. The built-in lip holds them in place and automatically steps each layer back 1/2". The Wedgies™ retaining wall is simple to lay and beautiful to look at.

Wedgies™

Colors: Gray, Buff/Tan, Copper/Black, Charcoal/Gray, or Red/Black

Size: 8" Wide x 4" High x 6" Deep

Face: .22 Square Feet

Weight: 12.5 lbs.

210 per Cube plus Wood Pallet

Olde Worlde Stone

The Olde Worlde line is available in 3 standard color blends:

Copperline (Black and Copper Blend)
Colonnade (Black and Gray Blend)
Prairie Sand (Tan and Buff Blend)
Olde Worlde Accent

Size: 8" Wide x 4" High x 8" Deep

Face: .22 Square Feet

Weight: 17 lbs.

180 per Cube plus Wood Pallet

Olde Worlde Standard

Size: 16" Wide x 4" High x 8" Deep

Face: .44 Square Feet

Weight: 33 lbs.

90 per Cube plus Wood Pallet

Olde Worlde Cap

Size: 16" Wide x 4" High x 12" Deep

Weight: 54 lbs.

48 per Cube plus Wood Pallet

Olde Worlde Garden Wall

Size: 12" Wide x 4" High x 8" Deep

Weight: 33 lbs.

144 per Cube plus Wood Pallet
